Renesas M16C Series User Manual

Electrical characteristics
M30240 Group
Rev.1.00 Sep 24, 2003 Page 126 of 360
Table 1.39: Electrical Characteristics (Vcc=4.1~5.25V, Vss=0V, Ta= 0°C∼ 70°C, f(Xin) = 12MHz)
Note 1: Only high drive when Timer A is enabled and drive registers set for high drive mode.
Symbol Parameter Measuring condition
Standard
Unit
Min Typ Max
V
OH High output voltage
Port0, Port1, Port2, Port3, Port6,
Port71, P73,P75,P77,Port8
(except P85), Port10
IOH = -5mA, Vcc=5V 3.0 V
V
OH High output voltage Port 70,P72,P74,P76,P80 IOH = -10mA, Vcc=5V 3.0 V
V
OH High output voltage
Port0, Port1, Port2, Port3, Port6,
Port71, P73,P75,P77,Port8
(except P85), Port10
IOH = -200µA, Vcc=5V 4.7 V
V
OH High output voltage Xout
high power I
OH = -1mA, Vcc=5V 3.0 V
low power I
OH = -0.5mA, Vcc=5V 3.0 V
V
OL Low output voltage
Port0, Port1, Port2, Port3, Port6,
Port71, P73,P75,P77,Port8
(except P85), Port10
IOL = 5mA, Vcc=5V 2.0 V
V
OL Low output voltage High-drive mode Port 2 IOL = 10mA, Vcc=5V 2.0 V
V
OL Low output voltage
Port 70,P72,P74,P76,P80
NOTE 1
IOL= 10mA, Vcc=5V 2.0 V
V
OL Low output voltage
Port0, Port1, Port2, Port3, Port6,
Port71, P73,P75,P77,Port8
(except P85), Port10
IOL = 200µA, Vcc=5V 0.45 V
V
OL Low output voltage Xout
high power I
OH = 1mA, Vcc=5V 2.0 V
low power I
OH = 0.5mA, Vcc=5V 2.0 V
V
T+-VT- Hysteresis
TA0in to TA4in, INT0 to INT1,
AD
TRG
, CTS0, CTS1, CLK0, CLK1,
TA2out to TA4out, NMI, KI0 to KI15
Vcc=5V 0.2 0.8 V
V
T+-VT- Hysteresis RESET Vcc=5V 0.2 1.8 V
Iih High input current
Port0, Port1, Port2, Port3, Port6,
Port7,Port8, Port10,
RESET,
CNVss
VI = 5V, Vcc=5V 5.0 µA
Iil Low input current
Port0, Port1, Port2, Port3, Port6,
Port7, Port8, Port10,
RESET,
CNVss
VI = 0V -5.0 µA
R
PULLUP Pull-up resistance
Port0, Port1, Port2, Port3, Port6,
Port7, Port8, Port10
V
I = 0V, Vcc=5V 30 50 167 kΩ
RX
IN Feedback resistance, Xin 1.0 MΩ
V
RAM RAM retention voltage When clock is stopped 2.0 V
Icc Power supply current
Output pins
open, other
pins tied to Vss
Icc run with USB
ON (Mask)
80 mA
Icc run with USB
ON (OTP)
95 mA
Icc run with
USB OFF
50 mA
Ta=25°C
clock stopped
1 µA
Ta=70°C
clock stopped
20 µA
Ta=25°C
wait mode
with internal
clocks ON
8mA
Ta=25°C
wait mode
with internal
clocks OFF
4mA
