REXROTH IndraControl L40 Series User Manual

11-2 Ordering Information IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
1234 6789
1
05 1234 6789
2
05 1234 6789
3
0512346789
4
05
Example:
Abbrev.
Column
CML 4 0 . 2 - SP - 2 2 0 - NA - NNNN - NW
1. Product
1.1 Main unit . . . . = CM
2. Housing design
2.1 Inline. . . . . . . . . . . . = L
3. Line
3.2 LX800, 500MHz. . . . . = 40
4. Design
4.1 2 . . . . . . . . . . . . . . . . . . . . . . = 2
5. Communication interface
Abb. Abb.
SERCOS column PROFIBUS column
910
- N - N
X S X P
6. System configuration
Abb. Abb. Abb.
DRAM (MB)
column NvRAM (kB) column SRAM (MB) column
12 13 14
16 1 32 1 ohne 0
32 2 64 2 1 1
64 3 128 3 2 2
128 4
7. Fan
7.1 without . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = N
8. Digital inputs / outputs
8.1 8 inputs / 8 outputs . . . . . . . . . . . . . . . . . . . . . . . . = A
9. Additional design
9.1 none . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NNNN
10. Firmware
10.1 without firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NW
Typenschluessel-L40_1.EPS
Fig. 11-2: Type code of the IndraControl L40.2
CML40.2
