9-10 Structure of the Rexroth Inline Terminals IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
12
1
2
3
4
1
2
3
4
112,4 mm (4.425")
12,2 mm
(0.480")
12
1
2
3
4
1
2
3
4
12,2 mm
(0.480")
132 mm (5.197")
12
1
2
3
4
1
2
3
4
5
6
5
6
12,2 mm
(0.480")
137 mm (5.394")
A B C
Steckermaß.FH9
L: A Standard connector
B Shield connector
C Extended double-signal connector
Fig. 9-13: Connector dimensions
The connector depth is irrelevant as it has no effect on the overall module
depth.
Connectors
