REXROTH IndraControl L40 Series User Manual

11-4 Ordering Information IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
11.2 Accessories
Necessary Accessories (Connector Set)
The following connector set is required for connecting the
IndraControl L40:
Ordering designation Part number Description
R-IB IL CML S01-PLSET R911299856 Connector set for IndraControl L40
Additional Accessories (Blower, Function Modules, Inline Modules and
Interface Cables)
Blower
Ordering designation Part number Description
CAL01.1-F1 R911306144 Blower
Rexroth Function Modules
Ordering designation Part number Description
CFL01.1-Y1 R911170007 SRAM
CFL01.1-V1 R911170001 DeviceNet master
CFL01.1-P1 R911170005 Profibus master
CFL01.1-R3 R911170008 Sercos III
CFL01.1-Q2 R911170009 Cross communication
CFL01.1-E2 R911170365 Cam switch
CFL01.1-N1 R911170012 Fast I/O
Rexroth Inline Modules
Ordering designation Part number Description
Digital input terminals:
R-IB IL 24 DI 2 R911289286 2 inputs, 24 V DC, 4-wire connection, width: 12.2 mm
R-IB IL 24 EDI 2-DES R911289292 2 Desina diagnostic inputs, overall width: 12.2 mm
R-IB IL 24 DI 4 R911289287 4 inputs, 24 V DC, 3-wire connection, width: 12.2 mm
R-IB IL 24 DI 8 R911289288 8 inputs, 24 V DC, 4-wire connection, width: 48.8 mm
R-IB IL 24 DI 16 R911289290 16 inputs, 24 V DC, 3-wire connection, width: 48.8 mm
R-IB IL 24 DI 32/HD R911297188 32 inputs, 24 V DC, 1-wire connection, width: 48.8 mm
