7-6 Connections and Interfaces IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
Note: Voltages U
M
and U
S
are electrically isolated from U
L
.
Requirement: Power supply units that are electrically isolated
from the power supply unit for U
LS
are used for voltages U
M
and U
S
.
Note: When designing the station, please note that because of the
common GND the total current in the segment circuit U
S
and
the main circuit U
M
must not exceed 8 A.
Note: U
M
is interrupted by the terminal PWR IN.
U
S
is interrupted by the terminals PWR/IN and SEG/F.
Internally Generated Voltages
+7.5 V Inline Supply U
L
The +7.5 V Inline supply voltage U
L
is generated from the supply voltage
U
LS
inside the IndraControl L40 and is supplied through all connected
Rexroth Inline I/O modules by the lateral contacts.
Logic voltage is supplied from the Inline voltage to all modules of the
station.
The voltage in this circuit is 7.5 V.
The Inline voltage is generated from the supply voltage U
LS
of the
IndraControl L40.
The maximum current carrying capacity of the Inline voltage is 2 A. Thus,
the total current consumption of all Inline modules must not exceed this
value of 2 A.
+24 V Analog Supply (UANA)
The +24 V analog voltage is generated from the voltage U
LS
. It starts in
the IndraControl L40 and is supplied through all Rexroth Inline I/O
modules by the lateral contacts (voltage jumper).
The output signals of the analog modules are generated from the analog
circuit in the analog terminals.
The voltage in this circuit is 24 V.
The analog voltage U
ANA
is generated from the supply voltage U
LS
of the
IndraControl L40.
The maximum current carrying capacity of U
ANA
is 0.5 A.
Function
Voltage
Generation of the Inline Supply
Voltage
Current Carrying Capacity
Function
Voltage
Generation
Current Carrying Capacity
