7-34 Connections and Interfaces IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
Output connector X2O1 connection Output connector X2O2 connection
Output 0 Output 0
Output 1 Output 1
Output 2 Output 2
Output 3 Output 3
Output 4 Output 4
Output 5 Output 5
Output 6 Output 6
Output 7 Output 7
Fig. 7-49: Output connectors X2O1 and X2O2
Feeder connector X1S connection
24 V (+)
GND (-)
FE
FE
Fig. 7-50: Feeder connector X1S
Note: The function module must be grounded with two 1.5 mm²
conductors at the FE plug and socket connections. These
conductors must have a length of maximum 1 m.
The FE functional earth ground is intended to discharge
disturbances. It is not provided as a protection against electric
shock for persons.
The status LED shows three states:
Light-emitting
diode Stat
Meaning
Green Supply voltage available.
Red Short-circuit or overload.
Off Supply voltage of the control is missing.
Fig. 7-51: States of the status LED
Light-emitting diodes indicating the current status of the outputs are
arranged besides the output terminals. They are connected on the quiet
side and thus do not indicate the current output voltage.
Interfaces
Indicators
