REXROTH IndraControl L40 Series - Fig. 7-16: Data of Digital Outputs

7-10 Connections and Interfaces IndraControl L40
DOK-CONTRL-IC*L40*****-PR03-EN-P
Number of outputs 8
Connection method 2-wire connection
Output type
• Semiconductor outputs,
non-saving
• Protected, with automatic
restart
• Current-carrying
Electrical isolation from U
S
No
Electrical isolation from U
L
Yes
Output voltage, nominal value 24 V
Rated output current:
Nominal value
Maximum value according to DIN EN 61131-2
1-signal
0-signal (leakage current)
UL-Rating:
General Purpose
Tungsten
0.5 A
≤ 0.6 A
2 mA ... 0.6 A
≤ 0.5 mA
0.5 A
5 W
Maximum total current of outputs 2 A
Parallel connection of outputs Yes, but only within one
terminal
Output delay time < 500 µ s
Contactor size (at 1 Hz) SG1 (6.2 W)
Lamp load (at 8 Hz) 5 W
Switching frequency
With ohmic load
With inductive load
100 Hz
Function (contactor)
Overload protection:
• Typical current level,
causing switch-off
• Minimum current level,
causing switch-off
• Automatic restart with reduced load
1.2 A
0.6 A
After approx. 10 msec
Overload indicator Red collective LED for all 8
outputs
Voltage reduced on circuit interruption in the
nominal operating mode
Electronically limited to
(Vext – 50 V)
Typ. 26 V
Reverse voltage protection Ensured without connected
load
Supply voltage according to EN 61131-2 24 V DC
Open-circuit power consumption from U
S
Typ. 50 mA
Cable length (unshielded) < 100 m
Fig. 7-16: Data of digital outputs
