REXROTH IndraControl L40 Series - Fig. 11-3: Type Code of the Function Modules

IndraControl L40 Ordering Information 11-3
DOK-CONTRL-IC*L40*****-PR03-EN-P
1. Product
1.1
Assembly group = CF
2. Housing design
2.1 Inline. . . . . . . . . . . . = L
3. Line
3.1 1 . . . . . . . . . . . . . . . . = 01
4. Design
4.1 1 . . . . . . . . . . . . . . . . . . . . . . = 1
5. Interface
5.1 without . . . . . . . . . . . . . . . . . . . . = NN
5.2 INTERBUS master. . . . . . . . . . . = B1
5.3 INTERBUS slave . . . . . . . . . . . . = B2
5.4 Fast I/O (In-/Ouput modules with
8xI / 8xO and 8xI/O configurable = E2
5.5 LAG: 2 encoder EnDat. . . . . . . . = G2
5.6 LAG: 1 encoder EnDat and
sensor probe . . . . . . . . . . . . . . . = G3
5.7 CanOpen master . . . . . . . . . . . . = K1
5.8 CanOpen slave . . . . . . . . . . . . . = K2
5.9 ASi master module . . . . . . . . . . = M1
5.10 PLS module . . . . . . . . . . . . . . . . = N1
5.11 PROFIBUS-DP Master . . . . . . . = P1
5.12 PROFIBUS-DP Slave . . . . . . . . = P2
5.13 Cross communication . . . . . . . . = Q2
5.14 Sercos 3. . . . . . . . . . . . . . . . . . . = R3
5.15
RT-Ethernet master, configurable
(PROFINET IO, EtherNet/IP, TCP/IP) = T1
5.16 DeviceNet master . . . . . . . . . . . = V1
5.17 DeviceNet slave. . . . . . . . . . . . . = V2
5.18 Memory, 8MB. . . . . . . . . . . . . . . = Y1
1234 6789
1
0512346789
2
0512346789
3
0512346789
4
05
Example:
Abbrev.
Column
CFL01 . 1 -P1
Typenschluessel-FM.EPS
Fig. 11-3: Type code of the function modules
Function Modules
