8.2 Mechanical Installation of Rexroth Inline Modules
Rexroth Inline modules can be added in series to the right of the
IndraControl L40 as appropriate. No tool is required. On connecting these
modules in series, the potential and bus signal connection (voltage and
data routing) between the individual components of the station is
established automatically.
The modules must be mounted perpendicularly to the top-hat rail.
Once the station has been set up, individual modules can be replaced
subsequently by being pulled out or plugged in without any additional
tools.
The Rexroth Inline modules must be mounted to the right of the
IndraControl L40 on the 35 mm standard top-hat rail.
Mounting the Inline Modules
Proceed as follows to latch on a module (Fig. 8-4):
• First latch on the electronic sockets, which are required to set up the
station, perpendicularly to the top-hat rail (Fig. A).
Note: Ensure that all feather keys and keyways of neighboring
modules are interlocked (Fig. B).
The keyway/feather key connection connects neighboring modules to
each other and ensures, that the voltage jumper is set up securely.
• Then fit the connectors onto the pertinent sockets.
First fit the forward connector shaft latch in the forward release
mechanism (Fig. C).
Then press the connector towards the socket until it clicks into place in
the rear release mechanism (Fig. D).
Note: The keyways provided in the electronic socket are not
continued in the connector. An electronic socket can only be
latched on, if there is no connector to the left of it. If
necessary, the latter must be removed.
Top-Hat Rail
