IndraControl L40 Connections and Interfaces 7-23
DOK-CONTRL-IC*L40*****-PR03-EN-P
CFL01.1-P1 Profibus DP Master Function Module
CFL01.1-Y1.tif
A S1, switch for slot number
B Stat, status indicator of the function module
C Bus, DP status
D X7P, Profibus DP connector
E Mounting rail interlock
Fig. 7-34: Profibus DP master function module
Note: Cable fixing during installation required!
