REXROTH IndraControl L40 Series - Fig. 7-46: Data of Digital Outputs

IndraControl L40 Connections and Interfaces 7-31
DOK-CONTRL-IC*L40*****-PR03-EN-P
Number of outputs 16 (8 of the 16 can be selected bit by
bit as input or output)
Connection method 1-wire connection
Output type Semiconductor outputs, non-saving
Protected, with automatic restart
Current-carrying
Electrical isolation to the logic supply Yes
Output voltage, nominal value 24 V
Rated output current:
Nominal value
Maximum value according to DIN EN
61131-2
1-signal
0-signal (leakage current)
UL rating:
General Purpose
Tungsten
0.5 A
≤ 0.6 A
2 mA ... 0.6 A
≤ 0.5 mA
0.5 A
5 W
Parallel connection of outputs Yes, but only within one half byte (0-
3;4-7 etc.)
Maximum total current of outputs 4 A
Output delay time (ohmic load)
If "0" to "1"
If "1" to "0"
Typ. 70µs, max. 95 µ s
Typ. 70µs, max. 75µs
Contactor size (at 1 Hz) (inductive
load)
SG1 (6.2 W)
Lamp load (at 8 Hz) 5 W
Overload protection:
Typical current level, causing switch-
off
Minimum current level, causing switch-
off
Automatic restart with reduced load
1.2 A
0.6 A
After approx. 10 ms
Overload indicator Red collective LED for all
16 outputs
Voltage reduced on circuit interruption
in the nominal operating mode, limited
to
Electronically limited to
(Vext – 50 V)
Typ. 26 V
Reverse voltage protection Ensured without connected load
Supply voltage according to EN
61131-2
24 V DC
Open-circuit power consumption from
24 V
Typ. 20 mA
Cable length (unshielded) < 100 m
Fig. 7-46: Data of digital outputs
Digital Outputs X2I1, X2D1
