IndraControl L40 Technical Data 4-1
DOK-CONTRL-IC*L40*****-PR03-EN-P
4 Technical Data
4.1 Equipment
Processor
1)
CML40.1: National Geode SC1200, at least with 266 MHz
CML40.2: AMD Geode LX800 with at least 500 MHz
Working memory CML40.1: At least 32 Mbytes DRAM and at least. 64 kbytes NvRAM
CML40.2: At least 64 Mbytes DRAM and at least 128 kbytes NvRAM
Interfaces:
Interface to functional
modules
• Bosch Rexroth PC104
Plus
Interface to I/O modules
• Rexroth Inline interface
Communication interfaces
• 1 x Ethernet connection (RJ 45, 10/100 Base-T)
• 1 x serial RS 232 interface
Optional:
• 1 x PROFIBUS DP master-slave interface
• 1 x SERCOS master interface
Ready Contact
Optional:
• 1 single-pin ready contact
Inputs and outputs
• 8 electrically isolated digital inputs
• 8 electrically isolated digital outputs
Fig. 4-1: Equipment
1)
For information on the processor and working memory of your
IndraControl L40 please refer to the particular system-specific manual.
4.2 Power Supply
The IndraControl L40 is supplied with a voltage of 24 V. The following
values of the operating voltage comply with DIN EN 61131-2:
Nominal value 24 VDC
Tolerances -15 % / +20 % (without residual ripple)
Residual ripple + / - 5 %
Umax 30 V
Umin 19.2 V
The IndraControl L40 requires three operating voltages (see chapter
"External Supply Voltages" on page 7-2). Current consumption from these
voltages is as follows:
Current consumption by U
LS
Max. 2.6 A
Current consumption by U
M
and U
S
Max. 8 A in total
Fig. 4-2: Current consumption
