REXROTH IndraControl L40 Series - 5 Dimensions; 5.1 Housing Dimensions

IndraControl L40 Dimensions 5-1
DOK-CONTRL-IC*L40*****-PR03-EN-P
5 Dimensions
5.1 Housing Dimensions
The IndraControl L40 housing is 175.4 mm long, 120 mm high and
75.9 mm deep. Please refer to the following figures for detailed
dimensions:
75,9 70,4 70,2
Maße_Unten.FH9
Fig. 5-1: Bottom view
120
175,4
126,7
Maße_Front.FH9
Fig. 5-2: Front view
