Ricoh M126 - Manual Feed Clutch Removal

Removal Procedures
SM 4-35 M126/M127/M128
Replacement
and
Adjustment
4.2.23 MANUAL FEED CLUTCH REMOVAL
1. Left side cover ( p.4-26 "Left Side Cover Removal")
2. Open the front access door, and disconnect the fuser link (A).
3. Place the printer on its right side.
 Be careful to not mar the finish of the printer.
4. Remove the four screws (B) from the main motor gear drive.
5. Rotate the main motor gear drive enough to access the manual feed solenoid.
