Ricoh M126 - Upper Front Guide Assembly Removal

Removal Procedures
SM 4-71 M126/M127/M128
Replacement
and
Adjustment
4.2.50 UPPER FRONT GUIDE ASSEMBLY REMOVAL
1. Open the front access door.
2. Remove the four screws (A) from the upper front guide.
3. Upper front guide.
4.2.51 WEAR STRIP (TRAY 1 AND 250-SHEET TRAY 2) REMOVAL
1. Hold the tray with the bottom up.
2. Use a spring hook to disconnect the strip from the top of the tray.
3. Remove the strip from inside the tray.
