Dimensions (W x D x H): 420 x 513 x 145 mm (16.5" x 20.2" x 5.7")
Weight 4.0 kg (8.8 lbs.)
Shift Tray Unit (D583)
Paper Size:
Standard Size:
A6 LEF to A3, HLT LEF to DLT
Non-standard Size:
Width: 90 to 305 mm, Length: 148 to 600 mm
Paper Weight: 57 to 157 g/m
2
(14 to 42 lbs.)
Tray Capacity:
125 sheets (80 g/m
2
, 20 lbs.): B4 or larger
250 sheets (80 g/m
2
, 20 lbs.): A4 or smaller
Power Source: DC 5 V, 24 V (from copier)
Power Consumption:
Max: 4.4 W
Average: 3.9 W
Weight: 2 kg (4.4 lbs.)
Dimensions (W x D x H):
423 x 467 x 113 mm (16.7" x 18.4" x 4.4")(without basement)
423 x 469 x 122 mm (16.7" x 18.5" x 4.8") (with basement)
Paper Feed Unit (D579)
Paper Size: A5 to A3, 5
1
/
2
" x 8
1
/
2
" SEF to 11" x 17"
Paper Weight: 52 – 157 g/m
2
, 14 – 42 lbs.
Tray Capacity: 550 sheets (80 g/m
2
, 20 lbs.) x 1 tray
Paper Feed System: FRR
Paper Height Detection: 5 steps (100%, 70%, 30%, 10%, Empty)
1. Appendix: General Specifications
28
