Ricoh OR-C1 - Installation Procedure

Installation Procedure
• Unplug the copier power cord before starting the following procedure.
1. Remove all tapes and shipping retainers.
• When unloading the ARDF from a pallet, hold the front and rear side of the ARDF.
2. Insert the two stud screws [A] on the top of the machine.
ARDF DF3060 (D578)
63
2
