Card Reader Bracket Type C3352 (D593)
Component Check
Check the quantity and condition of the accessories against the following list.
No Description Q'ty For This Model
1 Screw: M3 x 8 2 Yes
2 Screw: M3 x 14 1 Not used
3 Screw: M4 x 25 1 Yes
4 Tapping Screw: M3 x 10 3 Yes
5 Upper Tray 1 Yes
6 Lower Tray 1 Yes
7 Tray Bracket 1 Yes
Installation Procedure
1. Remove the upper right cover. ( p.182 " Upper Right Cover")
