Punch Kit PU3020 (D587)
This procedure explains how to install the punch kit for the internal finisher, after installing the internal
finisher.
Component Check
Check the quantity and condition of the components against the following list.
No. Description Q’ty
1 Punch Unit 1
2 Tray Lower Rear Cover 1
3 Punch Cover 1
4 Hopper 1
5 Screw: M3x6 7
6 Bracket 1
7 Tray Lower Front Cover 1
8 Front Right Lower Cover 1
Punch Kit PU3020 (D587)
105
2
