System SP Tables-4
SP4xxx: Scanner
4008*
Sub Scan Mag.Adjustment
Adjusts the magnification of the sub scan direction during scanning. Changing this
value changes the scanner motor speed. Press to toggle ±.
[–1 to 1 / 0 / 0.1% ]
4010*
L-Edge Regist Adjustment
Adjusts the leading edge registration for scanning. Press
to toggle ±.
[–2 to 2 / 0 / 0.1 mm ]
As you enter a negative value, the image moves toward the leading edge.
4011*
S-to-S Regist Adjustment
Adjusts side-to-side registration for scanning. Press to toggle ±.
[–2.5 to +2.5 / 0.0 / 0.1 mm step]
As you enter negative values, the image will disappear at the left, and as you enter
positive values, the image will appear at the left.
4012*
Scanner Erase Margin: Scale
Adjusts the erase margin at each side for scanning in book mode and ADF mode.
• Do not adjust this unless the user wishes to have a scanner margin that is greater
than the printer margin.
• These settings are adjusted to erase shadows caused by the gap between the
original and the scale of the scanner unit.
1
Book: Leading Edge [0 to 3.0 / 1.0 / 0.1 mm / step]
2 Book: Trailing Edge [0 to 3.0 / 0.0 / 0.1 mm / step]
3 Book: Left [0 to 3.0 / 1.0 / 0.1 mm / step]
System SP Tables-4
157
