4. Appendix: Service Program Mode
Tables
System SP Tables-1
SP1xxx: Feed
1001* Leading Edge Registration
2 Tray: Plain
Adjusts the printing leading edge registration from each
paper feed station using the Trimming Area Pattern
(SP2902 Pattern No. 10).
[–9.0 to +9.0 / +0.0 / 0.1 mm/step]
Use the key to toggle between + and – before
entering the value.
The specification is 3 ± 2 mm.
See "Replacement and Adjustment - Copy Adjustment"
for details.
3 Tray: Middle Thick
4 Tray: Thick
7 By-pass: Plain
8 By-pass: Middle Thick
9 By-pass: Thick
13 Duplex: Plain
14 Duplex: Middle Thick
1002* Side-to-Side Registration
1 By-pass Table
Adjusts the printing side-to-side registration from each
paper feed station using the Trimming Area Pattern
(SP2902 Pattern No. 10).
[–4.0 to +4.0 / +0.0 / 0.1 mm/step]
Use the key to toggle between + and – before
entering the value. The specification is 2 ± 1.5 mm. See
"Replacement and Adjustment - Copy Adjustment" for
details.
2 Paper Tray 1
3 Paper Tray 2
4 Paper Tray 3
5 Paper Tray 4
6 Duplex
1003* Paper Buckle
125
4
