System SP Tables-6
SP6xxx: Peripherals
6006* ADF Adjustment
1
Side-to-Side Regist: Front
Adjusts the side-to-side registration of originals with the ARDF.
[-3.0 to 3.0 / 0 / 0.1 mm/step ]
2
Side-to-Side Regist: Rear
Adjusts the side-to-side registration of originals with the ARDF.
[-3.0 to 3.0 / 0 / 0.1 mm/step ]
3
Leading Edge Registration
Adjusts the leading registration of originals with the ARDF.
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
5 Buckle: Duplex Front Adjust the amount of paper buckle to correct original
skew for the front and rear sides.
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
6 Buckle: Duplex Rear
7
Rear Edge Erase
Adjusts the erase margin at the original trailing edge.
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
6007
ADF Input Check
Displays the signals received from the sensors and switches of the ARDF. Only Bit 0 is
used for ADF input check.
4. Appendix: Service Program Mode Tables
248
