1. Place the test chart on the exposure glass and make a copy from one of the feed stations.
2. Check the magnification ratio. Use SP4-008 (Scanner Sub Scan Magnification) to adjust if
necessary. Specification: ±0.9%.
ADF Image Adjustment
Registration
A: Leading Edge Registration
B: Side-to-side Registration
Copy Adjustments: Printing/Scanning
277
