1 Bin Tray BN3090 (D582)
Component Check
Check the quantity and condition of the components against the following list.
No. Description Q'ty
1 Support Bar Cover 1
2 Tray Support Bar 1
3 Guide Mylar 1
4 1 Bin Tray Unit 1
5 Tray 1
6 Tapping Screw M3 x 8 2
Installation Procedure
• Unplug the copier power cord before starting the following procedure.
1. Remove all tapes.
2. Installation
66
2
