Transfer Unit
• Turn off the main power switch and disconnect the power cord before you start any of the
procedures in this section.
Transfer Roller Unit
1. Open the right cover [A].
2.
Replace the transfer roller unit [B] (Hook x1).
• Do not touch the transfer roller surface.
Image Density Sensor
1. Open the right cover.
2. Remove transfer roller unit. ( p.221 "Transfer Roller Unit")
Transfer Unit
221
4
