2.
Replace the upper feed clutch [A] (
x1,
x1,
x1).
3.
Replace the lower feed clutch [B] (
x1,
x1,
x1).
Paper Size Sensors
1.
Remove:
•
Upper rear cover (
p.181 "Upper Rear Cover")
•
Lower rear cover (
p.181 "Lower Rear Cover")
2.
Pull out the 1st and 2nd paper trays.
Paper Feed
239
4
240
242
