When loading envelopes or letterhead paper, confirm the orientation, face and back, or location
of flaps.
page 277 "Envelope Orientation and Recommended Status"
page 281 "Loading Orientation-fixed Paper or Two-sided Paper"
5. Put your fingers on the dimples on the front and rear paper guides and align the paper
guides to the paper size.
If the guides are not flush against the paper, images might be skewed or paper misfeeds might
occur.
6. While holding the paper guides with your hands, lock both of the paper guides again.
Make sure that the total of the gaps between the paper and the front and rear paper guides does
not exceed 0.75 mm (0.03 inches).
7. Specify the paper settings.
page 289 "Overview of Paper Settings"
• To load paper on the bypass tray, it is better to orient it in the direction of .
• Certain types of paper might not be detected properly when placed on the bypass tray. If this
happens, remove the paper and place it on the bypass tray again.
• You do not need to pull the extender out if the banner sheet guide tray is installed.
Loading Paper into the Paper Tray
209
