Ricoh Pro C5300S - Booklet Finisher SR5100 (Saddle Stitch)

Booklet Finisher SR5100 (Saddle Stitch)
DRC638
Push in the cartridge
lever until it clicks.
Return the staple unit
to its original position.
Close the finisher
front cover.
Push in the cartridge
gently.
Close the face plate
of the cartridge until
it clicks.
Remove jammed
staples.
Open the face plate.Pull out the cartridge.Pull out the cartridge
lever.
Open the finisher front
cover.
Pull out the staple unit.
11. Troubleshooting
462
