07: Finishing: Finisher
0701: Punch Position: With Feed
Adjust the horizontal position of the punch holes when using Finisher SR5090 or Booklet Finisher
SR5100.
Press [ ] to move the position toward the top edge (left) relative to the paper feed direction, or [ ] to
move it toward the bottom edge (right).
Paper feed direction
Paper feed direction
2 Holes Top
2 Holes Left
CVK008
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
2 Holes Type JP / EU
3 Holes Type US
4 Holes Type EU
4 Holes Type NE
2 Holes Type US
1 Hole Type JP
0.0 2.0 -2.0 0.5 mm
0702: Punch Position: Across Feed
Adjust the vertical position of the punch holes when using Finisher SR5090 or Booklet Finisher SR5100.
Press [ ] to move the position forward (up), or [ ] to move it backward (down).
10. Adjustment Settings for Operators
330
