• Output rollers (4 rollers on the lower side)
Turn the blue jammed paper removal dial to rotate the roller while holding a damp cloth on
the output roller. Wipe around each of four rollers while rotating them, and then wipe the
rollers with a dry cloth to remove any water.
12. Lower the ADF input tray.
13. Close the ADF cover.
14. Firmly insert the plug of the power cord into the wall socket. Connect all the interface
cables that were removed.
15. Turn the main power switch on.
Cleaning the Paper Tray, Friction Pad, and the Paper Feed Roller
If the paper tray, friction pad, or paper feed roller is dirty, a multi-feed or misfeed might occur. Clean
these parts by following the cleaning procedure for Tray 1 described below. The cleaning procedure is
the same for the optional paper feed unit.
1. Turn off the machine and unplug the power cord.
2. Pull out the plug from the socket. Remove all the cables from the machine.
Maintaining Your Machine
183
