Rockwell Automation SMC Dialog Plus User Manual

Specifications
A-3
Electrical Ratings UL/CSA/NEMA IEC
Control Circuit
Rated Operation Voltage
①
100–240 VAC (–15%, +10%)
24 VAC (–15%, +10%)
24 VDC (–20%, +10%)
100–240 V~ (–15%, +10%)
24 V~ (–15%, +10%)
24 VDC (–20%, +10%)
Rated Insulation Voltage N/A 240 V~
Rated Impulse Voltage N/A 3000 V
Dielectric Withstand 1600 VAC 2000 Y~
Operating Frequency 50/60 Hz 50/60 Hz
Protection Against Electrical Shock N/A IP20
Power Requirements
Control Module 40VA
Heatsink Fan(s)
24A —
35A —
54A —
97A 45VA
135A 45VA
180A 45VA
240A 45VA
360A 45VA
500A 145VA
650A 320VA
720A 320VA
850A 320VA
1000A 320VA
Maximum Heat Dissipation (watts)
Controller Rating:
24A 110
35A 150
54A 200
97A 285
135A 490
180A 660
