Appendix B
Parameter Information
Table B.1 Parameter List
①
Read-only capability.
Group
Parameter
Description
Parameter
Number
Display
Units
Scale
Factor
Minimum Maximum
Default
Setting
User
Setting
Metering
①
Voltage
Phase A–B
1Volts1 — — ——
Voltage
Phase B–C
2Volts1 — — ——
Voltage
Phase C–A
3Volts1 — — ——
Current
Phase A
4Amps10 — — — —
Current
Phase B
5Amps10 — — — —
Current
Phase C
6Amps10 — — — —
Wattmeter 7 kW 10 — — — —
Kilowatt
Hours
8kWH1 — — ——
Elapsed
Time
9Hours1 — — — —
Power
Factor
10 — 100 — — — —
Motor Thermal
Usage
11 % 1 — — — —
Faults
Clear Fault 18 — — No, Yes No —
Fault
Buffer #1
①
19 — 1 — — — —
Fault
Buffer #2
①
20 — 1 — — — —
Fault
Buffer #3
①
21 — 1 — — — —
Fault
Buffer #4
①
22 — 1 — — — —
Fault
Buffer #5
①
23 — 1 — — — —
Basic Setup
SMC Option
①
14 — —
Standard, Soft Stop, Pump Control, Preset Slow
Speed, Smart Motor Braking, Accu-Stop, or Slow
Speed with Braking
—
Starting Mode 28 — — Soft Stop, Current Limit Soft Start
Ramp Time #1 30 Seconds 1 0 30 10
Initial Torque
#1
31 % LRT 1 0 90 70
Current Limit
Level
34 % FLC 1 50 600 50
Kickstart Time 35 Seconds 10 0.0 2.0 0.0 (Off)
