8.1.5. Real-Time clock function
• This data logger module incorporates an accurate battery-backed real-time clock to display the date and time of day.
• It compensates for leap years.
• It does not automatically compensate for daylight saving in summer and winter.
• This clock is used to timestamp data within the data logger files. It is also used to date and time stamp the actual file.
• Note:
The date and time stamp of the file is the time the file was last written to (not the time when the file was first created).
• The battery is designed for a service life of around 10 years.
8.1.6. Setting the date & time
Requirements for setting:
1. Switch on the controller
2. No firing process in progress
Carry out setting:
Step
Display screen
Segment display
Description
Remark
1
Switch on the controller
2
Press the h key and hold it
down for at least 5 seconds until
“Date” setting mode appears.
The date is shown in
“YY.MM.DD” format.
3
21.01 01
Navigate to the flashing digit with
the
g or h key.
After the call-up, the numerical
value for the year flashes first.
4
21.01 01
Use the d and f keys to
change the flashing number.
5
21.01 01
Move onto the next digit with the
g key.
The last numerical value for the
day of the current date is in the
segment display.
6
21.01 01
Move to “Time” setting mode by
pressing the
g key from the
flashing day display.
7
01.01 01
Navigate to the flashing digit with
the
g or h key.
The time is now shown in
HH.MM.SS format.
8
01.01 01
Navigate to the flashing digit with
the
g or h key.
After the call-up, the numerical
value for the hour flashes first.
9
01.01 01
Use the d and f keys to
change the flashing number.
10
01.01 01
Move onto the next digit with the
g key.
The last numerical value for the
second of the current time is in
the segment display.
11
01.01 01
To exit Settings:
• Press the
g key while the
seconds display is flashing to
exit “Time” setting mode.
• Or wait 15 seconds.
