Step
Display screen
Icon
Description
Remark
8
630
Press the
g key.
The last set exhaust air flap
opening temperature is
displayed.
9
632
Enter the exhaust air flap opening
temperature by pressing the
d or f
key.
The keys can also be held down
for faster input.
10
632
To complete the configuration, press the
g key.
The newly entered temperature
values are saved and the
previous entries are reset at the
same time.
Note:
In the sequence described, it is important that the g key is pressed a total of four times, otherwise, changes will not be
saved.
Exhaust air flap operation sequence during firing:
No.
Description of the process
Indicator
1
The exhaust air flap is open before firing.
⇒ This can be helpful to allow any remaining moisture to escape from the kiln in a
controlled manner.
2
The exhaust air flap closes during the firing operation when the kiln reaches the specified
closing temperature.
3
The exhaust air flap opens again at the end of the firing process when the kiln has cooled
down naturally and the specified opening temperature has been reached.
Note:
The switch output (event) key has no function during exhaust air flap operation.
6.5.6. Programming the cooling system (ST 411 only)
NOTE
The introduction of cooling air using a blower or fan at a firing chamber temperature of more than
600°C can damage the insulating material or heating elements.
⇒ Cold air may only be brought in at a temperature below 600°C
.
⇒ The fan cooling system must never run during the firing process!
⇒ The cooling system is only switched on below 600°C when the kiln is in cooling mode and is
not being heated anymore!
⇒ The exhaust air opening must be open when a cooling blower or cooling fan is in operation.
⇒ Early cooling is not recommended as this can have a negative impact on the ceramics,
glazes and the durability of the kiln lining and the service life of the heating elements.
The manufacturer assumes no liability for damaged insulation material or heating elements if the
instructions have not been followed.
NOTE
The kiln must be prepared at the factory for the use of a cooling system with a blower or fan.
⇒ Retrofitting a cooling system with a blower or fan in a kiln without a cooling system is
generally not recommended.
⇒ Kilns with a cooling system are specially prepared and manufactured by the manufacturer for
use with a cooling system.
