Rohde ST411 - 11 Example of a Firing Program; Program Examples (Ceramics)

76 / 280
Step
Display screen
Icon
Description
Remark
5
P14-
The main display shows the first
configurable parameter.
6
P45-
The parameter to be configured
can be selected by pressing the
d and f keys.
7
0
The set value of the parameter to
be configured can be called up
with the
g key.
8
3
This can be altered by pressing the
d & f keys.
9
3
The
j key saves the value.
As an example, the value “3” (control of
the fan cooling system on the furnace)
has been set for parameter no. 45
(additional switching output) (see
Section 10.2.)
10
The control system display goes
dark for a moment and the control
system restarts.
11
20
After the restart, the control unit is
ready for operation again.
The set value is now permanently saved
for the respective parameter.
11. Example of a firing program
11.1. Program examples (ceramics)
Program no.
Description
Segment 1
“ Ramp rate”
Segment 1
“ Soak
temperature”
Segment 1
“ Soak period”
Segment 2
“ Ramp rate”
Segment 2
“ Soak
temperature”
Segment 2
“ Soak period”
Segment 3
“ Ramp rate”
1
Initial firing
1050°C
100°C/h 1050°C 00 h:00 min FULL/SKIP 1050°C
01 h:30
min
END
2
Biscuit firing
950°C
60°C/h 600°C 00 h:00 min 100 950°C
00 h:00
min
END
3
Earthenware
1050°C
150°C/h 900°C 00 h:00 min 100 1050°C
00 h:30
min
END
4
High-temperature
stoneware
1250°C
150°C/h 900°C 00 h:00 min 60 1250°C
00 h:05
min
END
