Roland SH-4d - DS -> Chorus (Distortion -> Chorus); DS -> Flanger (Distortion -> Flanger)

MFX Parameters
150
DS -> Chorus (Distortion -> Chorus)
Parameter
Value
Explanation
Dist Drive
0–127
Degree of distortion
Also changes the volume.
Dist Pan
L64–63R
Stereo location of the distortion sound
Cho
PreDly
0.0–100 [ms]
Adjusts the delay time from the direct sound until the chorus sound is heard.
Cho Sync
OFF, ON
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
C. Rate
0.05–10.00 [Hz]
Frequency of modulation
C.Rate Nt
Note(P.167)
Cho Depth
0–127
Depth of modulation
Cho Bal
D100: 0W–D0:
100W
Adjusts the volume balance between the sound that is sent through the chorus (W) and the
sound that is not sent through the chorus (D).
Level
0–127
Output Level
DS -> Flanger (Distortion -> Flanger)
Parameter
Value
Explanation
Dist Drive
0–127
Degree of distortion
Also changes the volume.
Dist Pan
L64–63R
Stereo location of the distortion sound
Flg PreDly
0.0–100 [ms]
Adjusts the delay time from the direct sound until the flanger sound is heard.
Flg Sync
OFF, ON
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
F. Rate
0.05–10.00 [Hz]
Frequency of modulation
F.Rate Nt
Note(P.167)
Flg Depth
0–127
Depth of modulation
