Roland SH-4d - Tape Echo

MFX Parameters
140
Parameter
Value
Explanation
D.Time
1–1300
Delay time from when the original sound is heard to
when the delay sound is heard
D.Time Nt
Note(P.167)
Acceleration
0–15
Adjusts the speed which the Delay Time changes from
the current setting to a specified new setting.
The rate of change for the Delay Time directly affects
the rate of pitch change.
Feedback
-98–+98 [%]
Adjusts the proportion of the delay sound that is fed
back into the effect.
Negative (-) settings will invert the phase.
HF Damp
200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000,
2500, 3150, 4000, 5000, 6300, 8000, BYPASS [Hz]
Adjusts the frequency above which sound fed back to
the effect is filtered out.
If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
Low Gain
-15–+15 [dB]
Amount of boost/cut for the low-frequency range
High Gain
-15–+15 [dB]
Amount of boost/cut for the high-frequency range
Balance
D100: 0W–D0: 100W
Volume balance between the direct sound (D) and the
delay sound (W)
Level
0–127
Output Level
Tape Echo
A virtual tape echo that produces a realistic tape delay sound.
This simulates the tape echo section of a Roland RE-201 Space Echo.
Parameter
Value
Explanation
Mode
S, M, L, S+M, S+L, M+L,
S+M+L
Combination of playback heads to use
Select from three different heads with different delay times.
S: short
M: middle
L: long
Repeat
Rate
0–127
Tape speed
Increasing this value will shorten the spacing of the delayed sounds.
Intensity
0–127
Amount of delay repeats
Bass
-15–+15 [dB]
Boost/cut for the lower range of the echo sound
Treble
-15–+15 [dB]
Boost/cut for the upper range of the echo sound
Head S Pan
L64–63R
Independent panning for the short, middle, and long playback heads
Head M
Pan
L64–63R
Head L Pan
L64–63R
