Roland SH-4d - MIDI Implementation Chart (SYSTEM)

MIDI Implementation Chart
207
MIDI Implementation Chart (SYSTEM)
Function
Transmitted
Recognized
Remarks
Basic Channel
1-16, OFF
1-16, OFF
MODE
MODE3
MODE3
Note Number
0-127
0-127
transfer to selected part
Velocity
Note On
o
o
transfer to selected part
Note Off
x
x
transfer to selected part
After Touch
x
o
transfer to selected part
ControlChange
x
x
Program Change
LSB
0
0
MSB
85
85
PC
0-127
0-127
Pattern Change (*4)
System Exclusive
x
x
System Common
: Song Position
x
x
: Song Selec
x
x
: Tune Request
x
x
System Real Time
:Clock
o
o
:Start
o
o
:Continue
x
o
Same process as Start.
:Stop
o
o
AUX Message
:All Sound Off
x
x
:Reset All Controllers
x
x
:Local On/Off
x
x
: All Notes Off
x
x
: Omni Mode Off
x
x
: Omni Mode On
x
x
: Mono Mode On
x
x
: Poly Mode On
x
x
: Active Sensing
o
o
: System Reset
x
x
Mode 1: Omni On, Poly Mode 2: Omni On, Mono o: Yes Mode 3: Omni Off, Poly Mode 4: Omni Off, Mono x: No
(*4) Send and receive only on the PATTERN screen. The program change is (bank number of the pattern you want to load) x 8 +
(pattern number) -1.
