Roland SH-4d - 2 Tap Pandly (2 Tap Pan Delay)

MFX Parameters
134
Para
met
er
Value Explanation
High
Gain
-15–+15 [dB]
Amount of boost/cut for the high-frequency range
Bala
nce
D100: 0W–D0: 100W
Volume balance between the direct sound (D) and the delay sound (W)
Leve
l
0–127
Output Level
2Tap PanDly (2 Tap Pan Delay)
Parameter
Value
Explanation
Delay Sync
OFF, ON
If this is ON, the delay synchronizes with the tempo.
D. Time
(ms)
1–2600
Adjusts the time until the second delay sound is heard.
D.Time
（
Nt
）
Note(P.167)
Delay Fbk
-98–+98 [%]
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Dly HF
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
1600, 2000, 2500, 3150, 4000, 5000, 6300,
8000, BYPASS [Hz]
Adjusts the frequency above which sound fed back to the effect is
filtered out. If you don’t want to filter out any high frequencies, set
this parameter to BYPASS.
Dly1 Pan
L64–63R
Adjusts the stereo location of delay 1.
Dly2 Pan
L64–63R
Adjusts the stereo location of delay 2.
Dly1 Lv
0–127
Adjusts the volume of delay 1.
Dly2 Lv
0–127
Adjusts the volume of delay 2.
Low Gain
-15–+15 [dB]
Amount of boost/cut for the low-frequency range
High Gain
-15–+15 [dB]
Amount of boost/cut for the high-frequency range
Balance
D100: 0W–D0: 100W
Adjusts the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent through the
delay (D).
Level
0–127
Output Level
