Specifications and Reference Data
91
Specifications and Reference Data
March 2017
Reference Manual
00809-0100-4108, Rev CA
M5 Digital Display
 2-Line, 5-Digit LCD for 4-20 mA HART
 2-Line, 5-Digit LCD for 1-5 Vdc HART Low Power
 Direct reading of digital data for higher accuracy
 Displays user-defined flow, level, volume, or pressure
units
 Displays diagnostic messages for local troubleshooting
 90-degree rotation capability for easy viewing
Configuration buttons
Rosemount 2088 now offers internal and external
configuration button options.
 Choosing option D4 will add external Analog Zero and
Span configuration buttons
 Choosing option DZ will add an external Digital Trim
configuration button
 Choosing option M4 (LOI) adds both internal and external
local configuration buttons.
Certain button options can also be combined as shown
below:
Bracket option
B4 Bracket for 2-in. Pipe or Panel Mounting
 Bracket for mounting of transmitter on 2-in. pipe or panel
 Stainless steel construction with stainless steel bolts
Button configuration
Option codes Internal External
DZ N/A Digital Trim
D4 N/A Analog Zero & Span
M4 LOI LOI
M4 + DZ LOI Digital Trim
M4 +D4 LOI Analog Zero & Span
