Field communicator menu trees and Fast Keys
March 2017
Reference Manual
00809-0100-4108, Rev CA
Field communicator menu trees and Fast Keys
117
Figure C-5. Field Communicator menu tree - service tools
Note
Selections with black circle are only available in HART Revision 7 mode. Selection will not
appear in HART Revision 5 DD.
C.2 Field communicator Fast Keys
A () indicates the basic configuration parameters. At minimum these parameters should
be verified as a part of configuration and startup.
A (7) indicates availability only in HART revision 7 mode.
Table C-1. Device revision 9 and 10 (HART7), DD revision 1 Fast Key sequence
Function
Fast Key sequence
HART 7 HART 5
Alarm and Saturation Levels 2, 2, 2, 5 2, 2, 2, 5
Damping 2, 2, 1, 1, 5 2, 2, 1, 1, 5
Primary Variable 2, 2, 5, 1, 1 2, 2, 5, 1, 1
Home
1 Overview
2 Configure
3 Service Tools
Trends
1 Pressure
2 Scaled Variable
3 Sensor Temperature
Pressure
1 Pressure
2 Status
Scaled Variable
1 Scaled Variable
2 Status
Sensor Temperature
1 Sensor Temperature
2 Status
Analog Output
1 Analog Output
Percent of Range
1 Percent of Range
Maintenance
1 Pressure Calibration
2 Analog Calibration
3 Restore Factory Calibration
4 Security
5 Locate Device
6 Device Reset
Pressure Calibration
1 Upper Sensor Trim
2 Lower Sensor Trim
3 Zero Trim
4 Damping
5 AO Transfer Function
6 Last Calibration Points
7 Sensor Limits
AO Transfer Function
1 Upper Calibration Points
2 Lower Calibration Points
LOI Password Protection
1 Password Protection
2 Configure Password
HART Lock
1 Device Lock
2 Lock/Unlock
Sensor Limits
1 PV Upper Limit
2 PV Lower Limit
3 PV Minimum Span
Security
1 Security Switch Status
2 External Buttons
3 Configuration Buttons
4 HART Lock
5 LOI Password Protection
Simulate
1 Loop Test
2 Pressure
3 Scaled Variable
4 Sensor Temperature
Active Alerts
1 Refresh Alerts
2 Active Alert 1
3 Active Alert 2
4 Etc.
Service Tools
1 Active Alerts
2 Variables
3 Trends
4 Maintenance
5 Simulate
Variables
1 Variable Summary
2 Pressure
3 Scaled Variable
4 Analog Output
5 Percent of Range
6 Sensor Temperature
