Reference Manual
00809-0100-4108, Rev CA
Configuration
March 2017
Configuration
Changing transmitter address using a Field Communicator
Changing transmitter address using AMS Device Manager
1. Right select on the device and select Configure.
2. In HART Revision 5 mode:
a. Select Manual Setup, select the HART tab.
b. In the Communication Settings box enter polling address in the Polling Address
box, select Send.
3. In HART Revision 7 mode:
a. Select Manual Setup, select the HART tab and select the Change Polling Address
button.
4. Carefully read the warning and click Yes if it is safe to apply the changes.
2.13.2 Communicating with a multidropped transmitter
To communicate with a multidrop transmitter, the Field Communicator or AMS Device
Manager has to be set up for Polling.
Communicating with a multidropped transmitter using a
Field Communicator
1. Select Utility and Configure HART Application.
2. Select Polling Addresses.
3. Enter 0–63.
Communicating with a multidropped transmitter using AMS
Device Manager
1. Select on the HART modem icon and select Scan All Devices.
From the HOME screen, enter the Fast Key
sequence
HART Revision 5 HART Revision 7
Device Dashboard Fast Keys
2, 2, 5, 2, 1 2, 2, 5, 2, 2
