62
Reference Manual
00809-0100-4108, Rev CA
Operation and maintenance
March 2017
Operation and maintenance
Performing a 4–20/ 1–5 V mA output trim using other scale
with a Field Communicator
From the HOME screen, enter the Fast Key sequence and follow the steps within the Field
Communicator to complete the 4–20 mA output trim using other scale.
Performing a 4–20 mA/ 1–5 V output trim using other scale
with AMS Device Manager
1. Right select the device and under the Method drop down menu, move cursor over
Calibrate and select Analog Calibration.
2. Select Scaled Digital to Analog Trim.
3. Follow screen prompts to perform a 4–20mA/ 1–5 V output trim.
5.6.3 Recalling factory trim—analog output
The Recall Factory Trim—Analog Output command allows the restoration of the as-shipped
factory settings of the analog output trim. This command can be useful for recovering from
an inadvertent trim, incorrect Plant Standard or faulty meter.
Recalling factory trim - analog output with a Field
Communicator
From the HOME screen, enter the Fast Key sequence and follow the steps within the Field
Communicator to complete the digital to analog trim using other scale.
Recalling factory trim - analog output with AMS Device
Manager
1. Right select the device and, under the Method drop down menu, move cursor over
Calibrate and select Restore Factory Calibration.
2. Select Next to set the control loop to manual.
3. Select Analog Output Trim under Select trim to recall and click Next.
4. Follow screen prompts to recall analog output trim.
Recalling factory trim - analog output with LOI
Reference Figure 5-7 for LOI instructions.
Device Dashboard Fast Keys
3, 4, 2, 2
Device Dashboard Fast Keys
3, 4, 3
