12
Reference Manual
00809-0100-4108, Rev CA
Configuration
March 2017
Configuration
Fast key sequences for the latest DD are shown in Tab le 2 -4 . For Fast Key sequences for
legacy DD's contact your local Emerson Representative.
Table 2-4. Rosemount 2088 and 2090F/P device dashboard Fast Key sequence
2.7.2 Verifying configuration with AMS Device Manager
Right select on the device and select Configuration Properties from the menu. Navigate
the tabs to review the transmitter configuration data.
2.7.3 Verifying configuration with local operator interface
Press any configuration button to activate the LOI. Select VIEW CONFIG to review the
below parameters. Use the configuration buttons to navigate through the menu.
The
parameters to be reviewed prior to installation include:
2.7.4 Verifying process variables configuration
This section describes how to verify that the correct process variables are selected.
Verifying process variables with a Field Communicator
Verifying process variables with AMS Device Manager
1. Right select the device and select Overview from the menu.
2. Select the All Variables button to display the primary, secondary, tertiary and
quaternary variables.
2.8 Basic setup of the transmitter
This section goes through the necessary steps for basic setup of a pressure transmitter.
From the HOME screen, enter the Fast Key sequences listed
Function
Fast Key sequence
HART 7 HART 5
Alarm and Saturation Levels 2, 2, 2, 5 2, 2, 2, 5
Damping 2, 2, 1, 1, 5 2, 2, 1, 1, 5
Primary Variable 2, 1, 1, 4, 1 2, 1, 1, 4, 1
Range Values 2, 1, 1, 4 2, 1, 1, 4
Ta g 2, 2, 7, 1, 1 2, 2, 7, 1, 1
Transfer Function 2, 2, 1, 1, 6 2, 2, 1, 1, 6
Units 2, 2, 1, 1, 4 2, 2, 1, 1, 4
Ta g Primary Variable
Units Range Values
Transfer Function Damping
Alarm and Saturation Levels
From the HOME screen, enter the Fast Key
sequence
Device Dashboard Fast Keys
3, 2, 1
