Product Certifications
97
Product Certifications
March 2017
Reference Manual
00809-0100-4108, Rev CA
B.1.9 Technical Regulations
Customs Union (EAC)
EM EAC Flameproof
Certificate: RU C-US.GB05.B.01197
Markings: Ga/Gb Ex d IIC T4/T6 X, T4(–40 °C
≤ T
a
≤
+80 °C), T6(–40 °C ≤ T
a
≤ +40 °C)
Special Condition for Safe Use (X):
1. See certificate for special conditions.
IM EAC Intrinsically Safe
Certificate: RU C-US.GB05.B.01197
Markings: 0Ex ia IIC T4 Ga X (–55 °C ≤ T
a
≤ +70 °C)
Special Condition for Safe Use (X):
1. See certificate for special conditions.
B.1.10 Combinations
K1 Combination of ED, I1, ND and N1
K2 Combination of E2 and I2
K5 Combination of E5 and I5
K6 Combination of C6, ED and I1
K7 Combination of E7, I7, NK and N7
KB Combination of K5 and C6
KM Combination of EM and IM
KH Combination of ED, I1, K5
B.1.11 Conduit Plugs and
Adapters
IECEx Flameproof and Increased Safety
Certificate: IECEx FMG 13.0032X
Standards: IEC60079-0:2011, IEC60079-1:2007-04,
IEC60079-7:2006-07
Markings: Ex de IIC Gb
ATEX Flameproof and Increased Safety
Certificate: FM13ATEX0076X
Standards: EN60079-0:2012, EN60079-1:2007,
IEC60079-7:2007
Markings: II 2 G Ex de IIC Gb
Special Conditions For Safe Use (X):
1. When the thread adapter or blanking plug is used
with an enclosure in type of protection increased
safety “e” the entry thread shall be suitably sealed in
order to maintain the ingress protection rating (IP) of
the enclosure.
2. The blanking plug shall not be used with an adapter.
3. Blanking Plug and Threaded Adapter shall be either
NPT or Metric thread forms. G
1
/2 thread forms are
only acceptable for existing (legacy) equipment
installations.
B.1.12 Additional Certifications
SBS American Bureau of Shipping (ABS) Type Approval
Certificate: 09-HS446883D-3-PDA
Intended Use: Measure gauge or absolute pressure of
liquid, gas or vapor applications on ABS
classed vessels, marine, and offshore
installations.
ABS Rules: 2014 Steel Vessels Rules 1-1-4/7.7,
1-1-Appendix 3, 4-8-3/1.7, 4-8-3/13.1,
4-8-3/13.3.1 & 13.3.2, 4-8-4/27.5.1
SBV Bureau Veritas (BV) Type Approval
Certificate: 23156/B0 BV
Requirements: Bureau Veritas Rules for the
Classification of Steel Ships
Application: Class notations: AUT-UMS, AUT-CCS,
AUT-PORT and AUT-IMS; Pressure
transmitter type 2088 cannot be
installed on diesel engines
SDN Det Norske Veritas (DNV) Type Approval
Certificate: TAA000004F
Intended Use: DNV GL Rules for Classification - Ships
and offshore units
Table 5. Conduit Plug Thread Sizes
Thread Identification mark
M20  1.5 – 6g M20
1
/2–14 NPT
1
/2 NPT
G
1
/2A G
1
/2
Table 6. Thread Adapter Thread Sizes
Male thread Identification mark
M20  1.5 – 6H M20
1
/2–14 NPT
1
/2–14 NPT
3
/4–14 NPT
3
/4–14 NPT
Female thread Identification mark
M20  1.5 – 6H M20
1
/2–14 NPT
1
/2–14 NPT
PG 13.5 PG 13.5
G
1
/2 G
1
/2
