Rosemount 2088 - Brazil; China; B.1.6 Brazil

Product Certifications
95
Product Certifications
March 2017
Reference Manual
00809-0100-4108, Rev CA
Special Conditions for Safe Use (X):
1. When fitted with a transient suppression terminal
block, the Rosemount 2088 is incapable of passing
the 500 V isolation test. This must be taken into
account during installation.
2. The enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish;
however, care should be taken to protect it from
impact or abrasion if located in a Zone 0
environment.
N7 IECEx Type n
Certificate: IECEx BAS 12.0072X
Standards: IEC60079-0:2011, IEC60079-15:2010
Markings: Ex nA IIC T5 Gc (–40 °C
≤ T
a
≤ +70 °C)
Special Condition for Safe Use (X):
1. When fitted with a transient suppression terminal
block, the Rosemount 2088 is incapable of passing
the 500 V isolation test. This must be taking into
account during installation.
NK IECEx Dust
Certificate: IECEx BAS12.0073X
Standards: IEC60079-0:2011, IEC60079-31:2008
Markings: Ex t IIIC T50 °C T
500
60 °C Da
Special Conditions For Safe Use (x):
1. Cable entries must be used which maintain the
ingress protection of the enclosure to at least IP66.
2. Unused cable entries must be filled with suitable
blanking plugs which maintain the ingress protection
of the enclosure to at least IP66.
3. Cable entries and blanking plugs must be suitable for
the ambient range of the apparatus and capable of
withstanding a 7 J impact.
B.1.6 Brazil
E2 INMETRO Flameproof
Certificate: UL-BR 15.0728X
Standards: ABNT NBR IEC60079-0:2008 + Errata
1:2011, ABNT NBR IEC 60079-1:2009 +
Errata 1:2011
Markings: Ex d IIC T* Gb, *T4(–20 °C
≤ T
a
≤ +80 °C),
*T6(–20 °C ≤ T
a
≤ +40 °C)
Special Conditions For Safe Use (x):
1. The material of the diaphragm shall not be subject to
environmental conditions that might adversely affect
the partition wall.
2. The pressure transducers are not intended to be
physically connected to a separate external source of
heating or cooling that could influence on its ambient
temperature rating.
3. For ambient temperature above +60 °C, use field
wiring rated to at least +90 °C.
4. The cable glands, thread adapters or plugs to be used
on the equipment shall be INMETRO certified.
I2 INMETRO Intrinsic Safety
Certificate: UL-BR 13.0246X
Standards: ABNT NBR IEC60079-0:2008 + Errata
1:2011, ABNT NBR IEC60079-11:2009
Markings: Ex ia IIC T4 Ga (–55 °C
≤ T
a
≤ +70 °C)
Special Conditions for Safe Use (X):
1. When fitted with a transient suppression terminal
block, the Rosemount 2088 is incapable of passing
the 500 V isolation test. This must be taken into
account when installing the equipment.
2. The enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish; however,
care should be taken to protect it from impact or
abrasion if located in Zone 0.
B.1.7 China
E3 China Flameproof
Certificate: GYJ15.1505
Standards: GB3836.1-2010, GB3836.2-2010
Markings: Ex d IIC T4/T6 Gb, T6(–20 °C ≤ T
a
≤ +40 °C),
T4(–20 °C ≤ T
a
≤ +80 °C)
Table 2. Entity Parameters
Parameter
HART
Voltage U
i
30 V
Current I
i
200 mA
Power P
i
0.9 W
Capacitance C
i
0.012 μF
Table 3. Input Parameters
Parameter
HART
Voltage U
i
36 V
Current I
i
24 mA
Table 4. Input Parameters
Parameter
HART
Voltage U
i
30 V
Current I
i
200 mA
Power P
i
0.9 W
Capacitance C
i
0.012 μF
