Reference Manual
00809-0100-4108, Rev CA
Configuration
March 2017
Configuration
Configuring scaled variable using a Field Communicator
1. Follow the screen prompts to configure Scaled Variable.
a. Select Linear under Select Scaled data options.
Configuring scaled variable using AMS Device Manager
1. Right select on the device and, select Configure.
2. Select the Scaled Variable tab and select the Scaled Variable button.
3. Follow screen prompts to configure Scaled Variable
a. Select Linear under Select Scaled data options.
Configuring scaled variable using a LOI
Refer to Figure 2-15 on page 21 for instructions to configure Scaled Variable using a LOI.
Figure 2-15. Configuring Scaled Variable Using a LOI
2.10.3 Re-mapping device variables
The re-mapping function allows the transmitter primary, secondary, tertiary, and
quaternary variables (PV, 2V, 3V, and 4V) to be configured as desired. The PV can be
remapped with a Field Communicator, AMS Device Manager, or a LOI. Variables (2V, 3V, and
4V) can only be re-mapped via Field Communicator or AMS Device Manager.
Note
The variable assigned to the primary variable drives the 4–20 mA (1–5 Vdc) output. This
value can be selected as Pressure or Scaled Variable. The 2, 3, and 4 variables only apply if
HART burst mode is being used.
From the HOME screen, enter the Fast Key sequence
Device Dashboard Fast Keys
2, 1, 4, 7
EXTENDED MENU
CALIBRAT
DAMPING
TRANSFER FUNCT
SCALED VARIAB
SCALED VARIAB
ASSIGN PV
TAG
ALARM SAT VALUES
PASSWORD
SIMLATE
HART REV
BACK TO MENU
EXIT MENU
SCALED VARIAB
VIEW SCALED
CONFIG SCALED
CONFIG SCALED
BACK TO MENU
EXIT MENU
VIEW CONFIG
ZERO TRIM
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXTENDED MENU
EXIT MENU
