Reference Manual
00809-0100-4108, Rev CA
Configuration
March 2017
Configuration
transmitter, a short pause allows the Field Communicator, AMS Device Manager, or a
control system to initiate a request.
Choosing burst mode options in HART 5
Message content options:
 PV only
 Percent of Range
 PV, 2V, 3V, 4V
 Process Variables
 Device Status
Choosing burst mode options in HART 7
Message content options:
 PV only
 Percent of Range
 PV, 2V, 3V, 4V
 Process Variables and Status
 Process Variables
 Device Status
Choosing a HART 7 trigger mode
When in HART 7 mode, the following trigger modes can be selected.
 Continuous (same as HART5 burst mode)
 Rising
 Falling
 Windowed
 On Change
Note
Consult your host system manufacturer for burst mode requirements.
Configuring burst mode using a Field Communicator
Configuring burst mode using AMS Device Manager
1. Right select on the device and select Configure.
2. Select the HART tab.
3. Enter the configuration in Burst Mode Configuration fields.
From the HOME screen, enter the Fast Key sequence
Device Dashboard Fast Keys
2, 2, 5, 3
