Troubleshooting
6.5 Reassembly procedures
6.5.1 Installing LOI/LCD Display
1. While aligning the captive screws with the respective holes on the electronics board,
connect the LCD/LOI display to the electronics board by pressing down firmly.
2. Make sure that the connecting pins on the back of the LCD fully connect to the front of
the electronics board.
3. Fully tighten down the captive screws
4. Replace the housing cover. The transmitter must be fully engaged to meet
Explosion-Proof requirementsInstalling terminal block.
6.6 Service support
Within the United States, call the Emerson Instrument and Valve Response Center using the
1-800-654-RSMT (7768) toll-free number. This center, available 24 hours a day, will assist
you with any needed information or materials.
The center will ask for product model and serial numbers, and will provide a Return Material
Authorization (RMA) number. The center will also ask for the process material to which the
product was last exposed.
For inquiries outside of the United States, contact the nearest Emerson representative for
RMA instructions.
To expedite the return process outside of the United States, contact the nearest Emerson
representative.
5. Emerson Instrument and Valve Response Center representatives will explain the
additional information and procedures necessary to return goods exposed to hazardous
substances.
Individuals who handle products exposed to a hazardous substance can avoid injury if
they are informed of and understand the hazard. The product being returned will
require a copy of the required Material Safety Data Sheet (MSDS) for each substance
must be included with the returned goods.
