Rosemount 2088 - A.6 Options; Options

Specifications and Reference Data
March 2017
Reference Manual
00809-0100-4108, Rev CA
Specifications and Reference Data
90
A.6 Options
Standard configuration
Unless otherwise specified, transmitter
is shipped as follows:
Custom configuration
If Option Code C9 is ordered, the customer may specify the
following data in addition to the standard configuration
parameters.
 Output Information
 Transmitter Information
 LCD display Configuration
 Hardware Selectable Information
 Signal Selection
Refer to the “Rosemount 2088 Configuration Data Sheet”
document number 00806-0100-4690.
Tagging (3 options available)
 Standard SST hardware tag is permanently affixed on
transmitter. Tag character height is 0.125 in. (3,18 mm),
84 characters maximum.
 Tag may be wired to the transmitter nameplate upon
request, 85 characters maximum.
 For HART protocols, the tag may be stored in transmitter
memory (eight characters maximum). Software tag is left
blank unless specified.
–- HART Revision 5: 8 characters
–- HART Revision 7: 32 characters
Optional Rosemount 306 integral
manifolds
Factory assembled to 2088 transmitters. Rosemount 306
Product Data Sheet
for additional information.
Other seals
Refer to Rosemount DP Level Product Data Sheet for
additional information.
Output information
Output range points must be the same unit of measure.
Available units of measure include:
Display and interface options
M4 Digital Display with LOI
(Rosemount 2088 only)
 Available for 4-20 mA HART, 4-20 mA HART Low Power
Engineering units
psi (all ranges)
4 mA (1 Vdc)
0 (engineering units)
20 mA (5 Vdc)
Upper range limit
Output
Linear
Flange type
Specified model code option
Flange material
Specified model code option
O-ring material
Specified model code option
Drain/vent
Specified model code option
LCD display
Installed or none
Alarm
High
Software tag
(Blank)
Pressure units
(1)
1. Field configurable only, not available for factory calibration or custom
configuration (option code C9 “Software configuration”).
torr psf(1) cmH
2
O@4°C(1)
atm inH
2
OmH
2
O@4°C(1)
Pa inH
2
O@4°C(1) inHg
kPa inH
2
O@60°F(1) mmHg
MPa
(1) ftH
2
OcmHG@0°C(1)
hPa(1) ftH
2
O@4°C(1) mHG@0°C(1)
mbar ftH
2
O@60°F(1) g/cm
2
bar mmH
2
Okg/m
2
(1)
psi mmH
2
O@4°C(1) kg/cm
2
